FEW Radiator Cap R121 (without Seal) - 49kPa 0.5kg (C-22, KH-C10)

Reference No.

R121

Read moreShow less

$7.50

Out Of Stock

Add to Wishlist0

Notify me when available

Tags:

16401-40120, 1640140120, 16401 40120, 16401-60120, 1640160120, 16401 60120, 19045-611-013, 19045611013, 19045 611 013, 0118-23-700, 011823700, 0118 23 700, MA111204, MT420320, 17920-65010, 1792065010, 17920 65010, 16401-46120, 1640146120, 16401 46120, 16401-60040, 1640160040, 16401 60040, R121, KH-C10, C-22

Description
Product Details

Description

Other Part Numbers

DAIHATSU

HONDA

MAZDA

MITSUBISHI

SUZUKI

TOYOTA

R121

C-22

KH-C10

• 16401-40120
• 16401-60120

• 19045-611-013

• 0118-23-700

• MA111204
• MT420320

• 17920-65010

• 16401-40120
• 16401-46120
• 16401-60040
• 16401-60120

Specifications

Fig. No.	FEW No	Pressure		Upper Seal	A	B	C	D
Fig. No.	FEW No	[kg/cm²]	[kPa]	Upper Seal	[mm]	[mm]	[mm]	[mm]
1	R111	0.9	88	X	60	21	26	38
2	R112	0.9	88	O
2	R135	1.1	108	O
3	R121	0.5	49	X	60	14	24	38
3	R122	0.9	88	X
4	R123	0.9	88	O
	R161	0.7	69
	R191	0.5	49
5	R117	1.2	118	O	46	11	21	29
	R124	0.9	88
	R128	1.0	98
	R148	1.1	108
	R153	1.1	108
	R154	1.3	127
6	R125	0.9	88	O	44	11	14	26
	R126	1.1	108
	R164	1.3	127
7	R141	1.05	103	X	60	21	25	39
8	R146	1.05	103	O		21	25
9	R142	1.05	103	X		11	31
