FEW Radiator Cap R123 - 88kPa 0.9kg (C-21, KH-C13, RGN-130)

Reference No.

R123

Read moreShow less

$7.50

Add to Wishlist0

Tags:

KH-C13, C-21, 022510-1730 JK, R123, NRC-091, MB007571, 16401-87702, 1640187702, 16401 87702, 16401-87703, 1640187703, 16401 87703, 16401-87704, 1640187704, 16401 87704, 16401-87706, 1640187706, 16401 87706, 16401-87709, 1640187709, 16401 87709, 19045-634-003, 19045634003, 19045 634 003, 19045-634-014, 19045634014, 19045 634 014, 19045-692-003, 19045692003, 19045 692 003, 19045-AA0-014, 19045AA0014, 19045 AA0 014, 19045-PA0-004, 19045PA0004, 19045 PA0 004, 19045-PA0-014, 19045PA0014, 19045 PA0 014, 19045-PD1-911, 19045PD1911, 19045 PD1 911, 0766-15-205, 076615205, 0766 15 205, SE01-15-205, SE0115205, SE01 15 205, MA152550, MB007570, 17920-63210, 1792063210, 17920 63210, 17920-78000, 1792078000, 17920 78000, 16401-36010, 1640136010, 16401 36010, 16401-36011, 1640136011, 16401 36011, 16401-41010, 1640141010, 16401 41010, 16401-41020, 1640141020, 16401 41020, 16401-41021, 1640141021, 16401 41021, 16401-48030, 1640148030, 16401 48030, 16401-49015, 1640149015, 16401 49015, MB110314MB221633

Description
Product Details

Description

Other Part Numbers

DAIHATSU

HONDA

MAZDA

MITSUBISHI

SUZUKI

TOYOTA

R123

C-21

KH-C13

NRC-091

RGN-130

• 16401-87601
• 16401-87702
• 16401-87703
• 16401-87704
• 16401-87706
• 16401-87709

• 19045-634-003
• 19045-634-014
• 19045-692-003
• 19045-AA0-014
• 19045-PA0-004
• 19045-PA0-014
• 19045-PD1-911

• 0766-15-205
• SE01-15-205

• MA152550
• MB007570
• MB007571
• MB110314
• MB221633

• 17920-63210
• 17920-78000

• 16401-36010
• 16401-36011
• 16401-41010
• 16401-41020
• 16401-41021
• 16401-48030
• 16401-49015

Specifications

Fig. No.	FEW No	Pressure		Upper Seal	A	B	C	D
Fig. No.	FEW No	[kg/cm²]	[kPa]	Upper Seal	[mm]	[mm]	[mm]	[mm]
1	R111	0.9	88	X	60	21	26	38
2	R112	0.9	88	O
2	R135	1.1	108	O
3	R121	0.5	49	X	60	14	24	38
3	R122	0.9	88	X
4	R123	0.9	88	O
	R161	0.7	69
	R191	0.5	49
5	R117	1.2	118	O	46	11	21	29
	R124	0.9	88
	R128	1.0	98
	R148	1.1	108
	R153	1.1	108
	R154	1.3	127
6	R125	0.9	88	O	44	11	14	26
	R126	1.1	108
	R164	1.3	127
7	R141	1.05	103	X	60	21	25	39
8	R146	1.05	103	O		21	25
9	R142	1.05	103	X		11	31
